Pipes & Tubes

  • Home
  • Pipes & Tubes

Our Products




Pipes & Tubes

Tubes are used in applications such as medical devices that require a precise outside diameter. The outside diameter is important since it will indicate how much it can hold as a stability factor. Pipes are used for transporting gasses or liquids making it important to know the capacity.

A pipe is a tubular section or hollow cylinder, usually but not necessarily of circular cross-section, used mainly to convey substances which can flow — liquids and gases (fluids), slurries, powders and masses of small solids.





Stainless and Duplex Steel

Duplex stainless steels are being increasingly used as structural materials in chemical and petrochemical applications, in power plants, etc. This is mainly due to their high resistance to localised corrosion as well as to their high strength and toughness.


Range 15 NB UP TO 1200 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS.
Form Seamless / Erw / Welded in Round & Square .
Stainless Steel ASTM / ASME SA 312 GR. TP 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316TI , 316H , 316 LN , 317 , 317L , 321 , 321H , 347 , 347 H , 904L . ASTM / ASME SA 358 CL 1 & CL 3 GR . 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316H , 321 , 321H , 347
Duplex Steel ASTM / ASME SA 790 UNS NO S 31803 , S 32205 , S 32550 , S 32750 , S 32760.







Carbon & Alloy Steel

Alloy steel and carbon steel both have very useful properties. Carbon steel is an alloy of iron and carbon, typically containing up to 2% carbon by weight. It is often utilized in the production of: machines, tools, steel buildings, bridges, and other infrastructure.


Range 15 NB UP TO 1200 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS
Form Seamless / Erw / Welded in Round & Square .
Carbon Steel ASTM / ASME A 53 GR. A , B
ASTM / ASME 106 GR. A , B ,C .
API 5L GR. B , API 5L X 42 , X 46 , X 52 , X 60 , X 70.
ASTM / ASME A 691 GRA , B ,C
Alloy Steel ASTM / ASME A 335 GRP 1 , P 5 , P 9 , P 11 , P 12 , P 22 , P 23 , P 91
ASTM / ASME A 691 GRP1 CR , 1 1/4 CR , 2 1/4 CR , 5 CR , 9CR , 91.






Nickel & Copper Alloy

Copper-nickel alloys are also used for hydraulic tubing, including brake tubing. Seawater cooling and firewater systems, heat exchangers, condensers and piping, platform riser and leg sheathing, boat hulls, oil coolers, hydraulic tubing, antimicrobial touch surfaces.


Range 15 NB UP TO 1200 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS
Form Seamless / Erw / Welded in Round & Square.
Nickel Alloy ASTM / ASME SB 163 UNS 2200 ( NICKEL 200 )
ASTM / ASME SB 163 UNS 2201 (NICKEL 201 )
ASTM / ASME SB 163 / 165 UNS 4400 (MONEL 400 )
ASTM / ASME SB 464 UNS 8020 ( ALLOY 20 / 20 CB 3 )
ASTM / ASME SB 704/705 UNS 8825 INCONEL (825)
ASTM / ASME SB 167 / 517 UNS 6600 (INCONEL 600 )
ASTM / ASME SB 167 UNS 6601 ( INCONEL 601 )
ASTM / ASME SB 704 /705 UNS 6625 (INCONEL 625)
ASTM / ASME SB 619/622/626 UNS 10276 ( HASTELLOY C 276 )
Copper Alloy ASTM / ASME SB 111 UNS NO. C 10100 , 10200 , 10300 , 10800 , 12000,12200, 70600 , 71500 . ASTM / ASME SB 466 UNS NO. C 70600 ( CU -NI- 90/10) , C 71500 ( CU -NI- 70/30)






Hastelloy

The alloy is used to manufacture high-temperature gas path components such as turbine combustors, flame holders, liners, pressure vessels of some nuclear reactors, chemical reactors, and pipes/valves in the chemical industry.


Grades Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000
Type Seamless / Erw / Welded/ Fabricated
Standard Hastelloy Seamless Pipe
Hastelloy ERW Pipe
This range is used in :
Petrochemicals Plants
Oil Refineries
Fertilizers Plants
Sugar Mills
Chemical Plants
Pharmaceuticals
Textile Machinery






Inconel

As such, pipes and tubes made with INCONEL alloy 625 can be used in sour gas pipelines, as well as in seawater heat exchangers, power plants and chemical processing. More recently, it's also found used in biofuel production as part of the superheater tubing systems.


Grades Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750
Type Seamless / Erw / Welded/ Fabricated
Range 15 NB up to 600 NB in SCH 5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 & XXS
Form Round, Square, Rectangular, Hydraulic etc.
Length Single Random Length,  Double Random Length,  Cut Length
Ends Plain End, Beveled End, Threaded
This range is used in Petrochemicals Plants
Oil Refineries
Fertilizers Plants
Sugar Mills
Chemical Plants
Pharmaceuticals
Textile Machinery






Monel

Its uses extend into gas storage units and process vessels, as well as in the pulp and paper industry. Due to its ability to withstand high operating temperatures, it's also a popular choice for heat exchanger piping and the explosives industry.


Grades Monel 400, Monel k500
Type Seamless / Erw / Welded/ Fabricated
Form Round, Square, Rectangular, Hydraulic etc.
Length Single Random, Double Random & Cut Length
End Plain End, Beveled End, Threaded
The salient features are as follows Hot Dipped Galvanizing
Epoxy & Fbe Coating
Electro Polish
Draw & Expansion






Titanium

Titanium pipe fittings are utilized in aircraft hydraulic systems, chemical processing plants, offshore drilling rig components, maritime and subsea equipment, and medical implants, among other applications.


Grades Grade 1, Grade 2, Grade 3, Grade 4, Grade 5, Grade 7, Grade 9, Grade 23
Type Seamless / Erw / Welded/ Fabricated
Range 15 NB UP TO 600 NB IN SCH 5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 etc.
Form Round, square, rectangular, hydraulic etc.
Length Single Random, Double Ranidom & Cut Length
End Plain End, Bevelled End, Treaded







STAINLESS STEEL, SEAMLESS / WELDED TUBES / PIPES & “U” TUBES


Size 6mm to 609.6mm
Thickness 0.5mm to 50mm
Length Random length – 4 to7mtr. Fixed Length up to 24mtr
Condition Hot Finish/Cold Finish, Annealed, Pickled & Passivated, Stress Relived, Bright Annealed.
Standards ASTM A 213, A 249, A 288, A 270, A 312, Equivalent DIN & BS standards
Grades Austenitic Series, Ferritic Series – 410 Duplex Special Alloy, 2 RK 65, 2 RE 69, Incoloy 600


Large Diameter S.S. Pipes (ERW)


Size 150mm to 1200mm
Thickness 4 mm to 16mm
Length Random Length 4 to 6mtr. Fixed Length up to 6mtr.
Condition Annealed, Pickled & Passivated Stress Relived
Standards ASTM A 312, A 358, A 409, A 554 & DIN & BS standards
Radius Straight Pipe only
Grades Austentic Series


Carbon Steel / Alloys Steel / Seamless Pipe / Tubes & “U” Tubes


Size Range 8mm to 800mm
Thickness 0.5mm to 50mm
Length Random Length 4 to 12mtr. Standard Fixed Length up 28mtr.
Condition Hot Finish / Cold Finish Heat Treated & Stress Relived, Bright Annealed.
Standards ASTM A53, A 106, A 179, A 192, A 210, A 333, A 334, A 335 BS 3059, P9, P11, P22, P91, BS-6323,BS-3059, Din 17175, Din 2391, JIS G 3461
Radius 1.5 D to 2 mtr. D U Bend
Grades Carbon Steel / Alloy Steel
