Circle

Circles

It is often used by architects for building envelopes, interior design and street furniture. SS 304 circle is durable has excellent corrosion resistance and rust. surgical tools, pulp and paper processing equipment, refining equipment, fasteners, and pharmaceutical processing, etc.

Material Specification Chart of SS 304 Blanks

Specifications	ASTM A240, ASME SA240
Dimensions	ASTM, ASME and API
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc.
Thickness	1 Mm To 100 mm.
Diameter	Upto 2000 Mm.
Circle Diameter	3″ DIA up to 38″ DIA 1500 lbs max.
Circles Form	Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Cnc Finish, Polished Unique, Hot Rolled Circle..

Stainless Steel 316 Blanks HSN Code

Hs Code	Description
7222	Other Bars And Rods Of SSS; Angles, Shapes And Sections Of SS
72224020	Of Below 80 Mm
72222012	Nickel Chromium Austenitic Type
72223099	Other
7301	Sheet Piling Of Steel Or Iron, Whether Or Not Drilled, Made From Assembled Elements or Punched ; Welded Angles, Shapes A
73012090	Other
7326	Other Articles Of Iron Or Steel
73269060	Manufactures Of SS

Composition Chart of ASTM A240 Stainless Steel 304 Circle

Grade	C	Mn	Si	P	S	Cr	Mo	Ni
SS 304	0.08 max	2 max	0.75 max	0.045 max	0.030 max	18 – 20	–	8 – 11
SS 304L	0.035 max	2.0 max	1.0 max	0.045 max	0.03 max	18 – 20	-	8 – 13
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 - 18.00	2.00 - 3.00	11.00 - 14.00
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	1.0 max	16.00 - 18.00	16.00 - 18.00	10.00 - 14.00

Stainless Steel Circle Polished Mechanical Properties Chart

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Various Types Of ASME Sa240 Steel Rolling Circle Cutter

SS Circle Equivalent Material Grade

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Stainless 304	1.4301	S30400	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10
Stainless 304L	1.4306 / 1.4307	S30403	SUS 304L	-	03Х18Н11	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11
Stainless 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	-	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
Stainless 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13		Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

Stainless Steel Circle Manufacturers In India, Huge Inbventory of 316 SS Circle, Check SS 202 Circle Weight Per Meter

Thickness Chart Of Stainless Steel Circle

Size	18 G.	19 G.	20 G.	22 G.	24 G.	26 G.
.4.5	.0-107	0-085	0-080	0-062	0.049	0-040
5	0-120	0-095	0-090	0-070	0-055	0-045
5.5	0-146	0-119	0-109	0-085	0-066	0-054
6	0-172	0-136	0-130	0-100	0-079	0-064
6.5	0-200	0-153	0-150	0-128	0-093	0-074
7	0-235	0-190	0-176	0-136	0-107	0-088
7.5	0.270	0.212	0.201	0-157	0-123	0-100
8	0-307	0-240	0-230	0-180	0-140	0-115
8.5	0-347	0-270	0-262	0-202	0-156	0-130
9	0-388	0-330	0-301	0-230	0-178	0-145
9.5	0-472	0-342	0-324	0-252	0-198	0-162
10	0-480	0-380	0-360	0-280	0-220	0-180
11	0-580	0-450	0-435	0-338	0-266	0-218
12	0-690	0-540	0-518	0-403	0-318	0-253
13	0-811	0-640	0-508	0-608	0-371	0-304
14	0-940	0-750	0-708	0-558	0-430	0-352
15	1-080	0-860	0-808	0-650	0-495	0-405
16	1-228	0-960	0-921	0-736	0-563	0-460
17	1-382	1-080	0-940	0-809	0-635	0-560
18	1-595	1-200	1-116	0-907	0-712	0-683
19	1-732	1-350	1-300	1-010	0-794	0-750
20	1-920	1-400	1-340	1-120	0-880	0-785
